Temwell Helical Band Pass Filters

Helical Band Pass Filters Features VHF, UHF, SHF, (S/4) Band Pass Filter Customized freq./B.W./I.L/ Attenuation Tunable 50 / 75 ohm 7H Series (42~1500 MHz) 7S Series (196~1500 MHz) 5W Series (230~2600 MHz) 5R Series (200~1650 MHz) 2, 3, 4 and 5 pole options available Toko/Murata replacement Filters For more info, contact Andrew

Continue reading

Coilmaster ML252010QP, ML252012QP, ML252012QS Series

ML252010QP, ML252012QP, ML252012QS Series : High current, low profile, miniature power inductors   ML252010QP Series Alternative to Murata p/n 1269AS-H Series https://www.coilmaster.com.tw/comm/upfile/p_180913_01689.pdf FEATURES High current carrying capacity in compact standard 1008 (2520 metric) footprint. Excellent current handling – up to 4.95 A; Exceptionally low DCR – only 25 mΩ Inductance rage: 0.47 µH – 4.7 µH […]

Continue reading

TDK Ferrite Magnetic Design Tool

The MDT software allows application-related parameters to be calculated for all available EPCOS ferrite cores and / or materials. It provides access to their digitized material data including their graphical representations. The user manual of the software contains a detailed description of all functions. The tool can be used as online version, tested in browsers […]

Continue reading
CRxxxxA-AS

Bourns CRxxxxA-AS Series

CRxxxxA-AS Series : New Sulfur-Resistant Fixed Resistors Features Thick film technology Power rating from 0.05W to 1W @ 70°C Wide resistance range from 1Ω to 20MΩ Available in 8 footprints from 0201 (0603 metric) to 2512 (6432 metric) RoHS compliant Halogen free Sulfur-resistant design (ASTM B-809) AEC-Q200 compliant For more info, contact Andrew Click here […]

Continue reading

Hammond 1554/5 Series

1554 & 1555 Series Type 4X, 6P Polycarbonate & General Purpose ABS Enclosures An additional 36 configurations have been added to the range Key features Sealed to IP68 >150 size options available Opaque, clear or smoked lids PCB guides, standoffs and DIN rail mounting tabs inside The polycarbonate versions are UV stabilised for outdoor use […]

Continue reading
Sensirion SVM30

Sensirion SVM30

Multi-Gas, Humidity and Temperature Module SVM30 The Solution for Air Purifiers and HVAC Applications The SVM30 facilitates development and sensor design-in of products while at the same time offering great flexibility for product design. The SVM30 is especially suited for customers which prioritize lean development and products, and perfectly fitting for small and middle-sized companies. […]

Continue reading

TDK B32354S3 Series

B32354S3 Series : Rugged AC filter capacitors with UL 810 approval The capacitors of the B32354S3 series are designed for a rated voltage of 350 V AC and are available with capacitance values of 10 µF to 40 µF. The lead spacing is 52.5 mm. Because of the segmented film structure, the new capacitors conform […]

Continue reading
Micro Fit+ Connectors

Molex Micro-Fit+ Connector

The Micro-Fit+ connector is a wire-to-board system which offers a 3.00mm pitch, a higher-current rating of 12.5A and superior design options for flexibility and efficient assembly Features and Advantages Fully isolated contacts on each side of the interface – Prevents potential arcing Reduced Mating Force by 40% – Allows for ease of work, reducing operator […]

Continue reading

Hammond Mfg RZ Series

RZ Series : Water-Tight ABS & Polycarbonate Enclosures The range consists of an initial 10 sizes from 52 x 50 x 35 to 222 x 146 x 75 mm, additional sizes will be added as the range is expanded. Key features Sealed to IP65 ABS body with a solid ABS or clear polycarbonate lid Polycarbonate […]

Continue reading
Bourns GMOV

Bourns Introduces GMOV™ Hybrid Overvoltage Protection Components

The GMOV™ line of hybrid overvoltage protection components combining the patented, space-saving FLAT™ Gas Discharge Tube (GDT) technology with a Metal Oxide Varistor (MOV) to create a compact and enhanced overvoltage protector that is a drop-in replacement for standard 14 and 20 mm MOVs. Features Hybrid design Compact form factor Matched MOV-GDT pairings Bourns GDT […]

Continue reading
molex-211624_Antenna2

Molex 211624 High-Accuracy Stacked Patch GNSS Antenna

GPS L1/L5 & GLONASS 36 x 36 x 7mm Stacked Patch Single Feed Antenna Features and Advantages Stacked-patch single feed – Eliminates the need for a separate base station Low-profile design – Affords space savings Silver pin – Positions and fixes the antenna to the PCB (via soldering); provides electrical contact between the antenna and […]

Continue reading
Displays

Displays

Electrocomp offers a wide variety of displays to cater for your HMI / visual needs TFT Displays Touch Screen Overlays (RTP, PCAP, etc) Touch Screen Monitors Character Monochrome Graphic Monochrome Character OLED Graphic OLED Electrophoretic (E-Paper) Custom LCD Displays Take your clients’ expectations to the next level and contact Fernando Da Silva to resolve your HMI needs

Continue reading
